Premium Tech Tool 2.7.30 is a tool that supports the repair and diagnostic process. It was developed to make repair shop tasks easier and more efficient. TT can be used in the repair shop, out in the field, at the roadside, or during test drives. TT is a diagnostics application that covers the whole repair process through the use of plug-ins. With TT you can diagnose, test, calibrate, and program a product. A product could be a vehicle, engine, or a machine. TT also provide functions for updating the tool, communication with the product, and other external applications. The set of plug-ins, user authorizations, and available languages is adjustable to provide every user with what they need.

The basic workflow in Tech Tool is the same for all products:

• Identify a product.

• View information history.

• Diagnose a selected product.

• Test a selected product.

• Program a selected product.

• Calibrate a selected product.

Supported companies and electrical systems with PARAMETER PROGRAMMING:

• Volvo Trucks (Older electrical system, Vehicle electrical system ’98);

• Volvo Trucks (VERSION2, VERSION3);

• Volvo Trucks (VERSION4 – FH4/FM4);

• Volvo Buses (Conventional, Multiplexed, Multiplexed v2, Multiplexed v3);

• Volvo Construction Equipment;

• Volvo Penta (VERSION2, VERSION3);

• Volvo OEM Component Customer (VERSION2, VERSION3);

• Mack Trucks (V-MAC I/II/III, ITC, IV, IV+);

• Renault Trucks (VERSION2, VERSION3, VERSION4);

• UD Trucks (VERSION2, VERSION3).

WORK WITH USA TRUCKS WITHOUT PROBLEMS

This release of Tech Tool 2.7 will include New features and Changes.

• The odometer (mileage) value of the connected product will now be shown in the Product Identification screen as well as recorded into Product History log.

• Tech Tool will now automatically detect any VOCOM adapter connected via USB.

• New version of VOCOM II firmware.

• Tech Tool now has the ability to read and clear fault codes communicating on J1939 (Example: Bendix Fusion system). Note that all fault tracing for Bendix Fusion must be done using Bendix ACOM.

• Updates to the Windows driver software (SW) and hardware device firmware (FW) for the Vocom II (88894000) have been released to address issues related to J1939 communication, operational performance and automatic update of Vocom II FW. These updates are found in Vocom II SW version “4.0.0.925” ALL CHANGES CHANGES YOU CAN FIND IN ATTACHMENTS

Tech Tool 2.7 includes the Vocom II version “4.0.0.925” with updates being handled in the Tech Tool Client Update (CLUP). The Vocom II will be updated automatically from TT 2.7 forward.

Attention: Windows 7 32/64 Ultimate or Proffesional or Enterprice With service pack 1

Note: Tech Tool does NOT support Windows XP. DONT WORK With Home Edition

Minimum Hardware Requirements:
Computer/Processor: Inter Core 2 Duo(1.6GHz) or equivalent AMD Athlon 64 X2
Memory(RAM): 3GB more memory improves performance
Hard Disk: 20GB of free hard disk space
Optical Drive: Internal/External DVD x8 drive
Display: XGA (1024x768 pixels) or highter resolution monitor with 16 bit color settings
Input Device: Keyboard and mouse or compatible pointing device
Internet Connection: Network 10 Mbps or higher speed adapter or WLAN or 33.6 Kbps or highter speed modem.(not supported Win7/8 clients)
Miscellanceous: USB interface required.A battery-pack that may provide 500mA via USB

Recommended Hardware Requirements:
Computer/Processor: Inter Core i5 or AMD FX 8 Core Series
Memory(RAM): 6GB more memory improves performance
Hard Disk: 120GB SDD (Solid State Drive) of free hard disk space
Optical Drive: Internal/External DVD x8 drive
Display: XGA (1024x768 pixels) or highter resolution monitor with 32 bit color settings
Input Device: Keyboard and mouse or compatible pointing device
Internet Connection: Network 10 Mbps or higher speed adapter or WLAN
Miscellanceous: USB interface required.A battery-pack that may provide 500mA via USB

System Requirements:

Type of Software	Version	Comments
Operation System	Win 7 Professional or Enterprise(32-bit/64 bit) Win8/8.1 Professional or Enteriprise (32-bit/64 bit) or Win10 Professional or Enterprise(32-bit/64 bit)	For Security reasons operating system service pack is required, the OS is updated through enabled Windows update function.
Operation System Setting	TCP/IP protocol installed Window update enabled Window firewall enabled Antivirus enabled	The settings or software are normally enbleed on a preinstalled computer.Note:If other firewalls than Windows firewall is used,Tech Tool and the Java version installed by Tech Tool should be added as exceptions for the firewall.
Network Settings	TCP-port 80 open(http traffic) TCP-port 443 open (https traffic) TCP-port 8891 open (http traffic)
Necessary System components (Include in the installation)	Microsoft Internet Explorer 9 or later	Tech Tool uses MS internet Explorer.
	Window Installer 3.1	For configuration service, to be able to update latest patches the supporting software
Web services	Window .NET Framwork 4.0	Required for tech tool and Client Update/FIDO
Database	SQL Server Compact Edition 3.5	For access to the databases. Note:SP3 for new users
Antivirus Software	Antivirus software approved by Microsoft	For security reasons Microsoft approved Antivirus software is required with the latest virus definition file.The recommendation is to use Symantec antivirus (with latest definition file) which is also required when running on VCN
