Overview
FlashPro400 is Production 4Gang programmer and for High-density, High-quality, High-speed.
Also support NOR, NAND with user file systems (Bad block Management).
It state-of-the-art programming algorithms optimize throughput, technology and high-speed, reliability and yields.FlashPRO400 also supports past download data via USB 2.0 and stand alone and Local mode operation.

2. Features
 Production 4 Gang Programmer (Module)For High-density, High-quality, High-speed
 Supports Nand Algoritnm to user’s Surroundings(Magic-eye, XSR, GBBM, EFS, RFS and so on)
 High-speed(4 Gang at once)Supports module type Adapter
 Stand-alone and Local mode operation
 Fast download data via USB 2.0
 Auto Start Button Function(E->B->P->V Working order institution possibility)

3.Specification

Device Support
 NOR FLASH memory,
 NAND FLASH memory
 CPLD, Microcontroler, Etc.
Device Contact
Socket Module
 4 Gang Module Adapter Supported Device Package
 DIP, SDIP, PDIP, LCC, PLCC, QFP, TQFP, PQFP, VQFP, SOIC, SOP, PSOP,SON, TSOP, TSOP2, STSOP, TSSOP, SSOP, BGA, uBGA, FBGA, EBGA, CSP, SCSP

ControlControl Processor
 32bit embedded RISC processor Device control functions
 Read, Program, Verify, Blank Check, Erase

Interface Port
 USB2.0 & RS232 (Max. 115.2K) ports.

Data Transfer RateHigh-speed Programming
 Up to 400Mbit/sec Via USB 2.0

Functions
System Control Functions
 Read, Program, Verify, Blank Check, Erase, Pgm, Seq, Cfg, Edit, Data, Check Sum, I/O, Device
Host Computer Requirements
 Pentium PC, 2000 / XP, USB 2.0 & serial ports, over 200Mbyte hard disk, over 256Mbyte RAM, CD-ROM drive
Supported File Formats
 Binary, ASCII, Intel HEX, Motorola S, TEK HEK, JEDEC, POF
PowerInput power
 110~230VAC, 50~60Hz Dimension
Dimensions
 264(D) * 345(W) * 97(H) mm.

Weight
 5.5 KG
Operating Temperature
  0-40oC(32-105 oF)
Product Model
 FLASHPRO 400B:Include 16Gbit buffer memory
